Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibrationDamping gear
1.Performa luar biasa
2.Konsumsi bahan bakar rendah
3.Efisiensi tinggi
4.Cocok untuk kondisi kerja lahan rawa, kolam ikan, kanal, sungai, dll.
| Spesifikasi teknis | ||
| Parameter dasar | ||
| Berat alat berat | 18600 | kg |
| Daya mesin | 86 | kW |
| Kapasitas bucket standar | 0.52 | m³ |
| Dimensi | ||
| Panjang Boom | 4600 | mm |
| Panjang Stick | 2250 | mm |
| Panjang Ponton | 7000 | mm |
| Lebar Ponton | 1250 | mm |
| Tinggi Ponton | 1600 | mm |
| Lebar Sasis | 3700 | mm |
| Parameter operasi | ||
| Kedalaman rendam maksimum | 1600 | mm |
| Efisiensi kerja | 100 | m³/jam |
| Tinggi penggalian maksimum | 9130 | mm |
| Tinggi pembuangan maksimum | 6740 | mm |
| Kedalaman penggalian maksimum | 4410 | mm |
| Kedalaman penggalian vertikal | 3145 | mm |
| Radius penggalian maksimum | 8065 | mm |
| Radius penggalian maksimum di permukaan tanah | 7720 | mm |
1.Performa luar biasa
2.Konsumsi bahan bakar rendah
3.Efisiensi tinggi
4.Cocok untuk kondisi kerja lahan rawa, kolam ikan, kanal, sungai, dll.
