Large displacement, high gradeability and high efficiency
Bosch high pressure common rail (HPCR) fuel injection system with the injection pressure up to 1,600 bar, achieving multiple injections and accurate control
High-strength alloy cast iron cylinder head
General engine block + independent crankcase
Long B10 service life design, which can be more than 500,000 km
Reduction soft meshing starter, ensuring smooth start
A framed engine body structure, ensuring good rigidity and small vibrationDamping gear
1. Multifungsi
2.Efisiensi tinggi
3.Tenaga yang kuat
4.Konsumsi rendah
5.Pengoperasian yang mudah
6.Perawatan yang mudah
| Parameter dasar | |
| Berat | 26650kg |
| Mesin | Cummins QSF3.8 |
| Daya nominal | 124/2050kW/rpm |
| Diameter maksimum | 600mm |
| Parameter kinerja | |
| Kecepatan slewing maksimum | 11 ~ 15r / mnt |
| Kecepatan jalan | 3,2/4,7km/jam |
| Tangki bahan bakar | 350L |
| Tangki hidrolik | 210L |
| Kemampuan menanjak | 35° |
| Parameter operasi | |
| Radius Kerja Maksimum | 8577mm |
| Kedalaman Kerja Maksimum | 5300mm |
| Tinggi Kerja Maksimum | 8900mm |
| Radius Putar Ekor Platform | 2830mm |
| Dimensi transportasi | |
| Panjang | 9465mm |
| Lebar | 3000mm |
| Tinggi | 4080mm |
| Parameter Lainnya | |
| Panjang Track | 4406mm |
| Gauge Track | 3610mm |
| Lebar Track | 600mm |
| Tinggi Antara | 782mm |
1. Multifungsi
2.Efisiensi tinggi
3.Tenaga yang kuat
4.Konsumsi rendah
5.Pengoperasian yang mudah
6.Perawatan yang mudah
